Plan Description

A contemporary family would be very comfortable in this unique layout for a 4-unit apartment townhouse building that includes two bedrooms. Each apartment's generous 196 square meters of floor space includes a cozy two bedrooms and three full bathrooms, in addition to a wealth of other wonderful spaces. The master bedroom is equipped with its own private bathroom for maximum comfort. This contemporary home features a living room, dining room, kitchen and a bathroom en-suite and a guest’s washroom. The duplex plan's compact size allows it to fit on a relatively small plot, as shown in the accompanying 4 unit apartment design plan, which measures 21 by 9 meters. The parking area in front of the duplex's living room is partially covered, and a canopy can be added to completely cover the parking area. With this addition, you'll have a place to park your car that's both secure and aesthetically pleasing, a must for any townhouse.

Design Features

Stories – 2, Bedrooms – 2, Baths – 3, Area – 209 Sq/m, Length – 16.6m, Width – 12.6m

HM-Concept

2 Bedroom Modern Townhouse Home Design- CD110043

2 Bedroom Modern Townhouse Home Design- CD110043

Regular price $749.00 USD
Regular price $1,500.00 USD Sale price $749.00 USD
Sale Sold out
Shipping calculated at checkout.
Item Cost Estimate
1: Substructure
2: Superstructure
3: Roof
4: Doors
5: Windows
6: Finishes
7: Decorations
8: Plumbing Installations
9: Electrical Installations
Total Cost
View full details
  • Design Specifications

    Foundation Plan
    Floor Plans
    Roof Plan
    Detailed Sections
    Construction Details
    Elevations
    Doors and windows schedule
    Floor finishes and furniture layout plan

    Electrical schematics
    Schematic electrical layout plan
    Schematic clean water layout plan
    Schematic foul water layout plan
    Septic tank and Soak-away pit details

    Fence wall design

  • Drawing List

    All Relevant Floor Plans

    Elevations

    Sections

    All Relevant Details

    Door and Window Schedule

    Furniture Layout

    Finishes Schedule

    Structural Drawings

    Mechanical Drawings

    Electrical Drawings

    3D Perspectives

    Bill of Quantities – Without Rates

    Schedule of Materials – Without Rates

    Fire and Security Systems Layout

    -

    DRAWINGS DELIVERED IN DWG AND PDF FORMATS
